24-Port 10/100Mbps PoE Unmanaged Switch RUIJIE RG-ES126S-LP
- Support 24 x 10/100 Mbps PoE/PoE+ Ports, 1 x 10/100/1000 Mbps uplink port and 1 x 10/100/1000 Mbps combo port.
- Switching capacity: 8.8Gbps.
- Package forwarding rate: 6.55Mpps.
- Power supply: 100-240V AC.
- Power consumption: 220W.
- PoE power budget: 180W.
Specifications
Ports | 24 x 10/100 Mbps PoE/PoE+ Ports 1 x 10/100/1000 Mbps uplink port 1 x 10/100/1000 Mbps combo port |
Operating mode | Half-duplex, full-duplex, auto-negotiation mode Support auto MDI/MDIX |
Switching capacity | 8.8Gbps |
Package forwarding rate | 6.55Mpps |
Power supply | 100-240V AC |
Surge protection | Switch-mode power supply: Common mode: ±6 kV Differential mode: ±6 kV Network ports: Non-PoE ports: ±4 kV PoE ports: ±6 kV |
Port Mode | “Flow Control On” “Flow Control Off” “Port Isolation” from left to right |
Power consumption | 220W |
PoE power budget | 180W |
Fan | Support |
Dimensions (W x D x H) | 440 x 180 x 44 mm |
Operating temperature | 0℃ to 45℃ |
Storage temperature | -40℃ to 70℃ |
Operating humidity | 10% to 90% RH |
Storage humidity | 5% to 95% RH |
- Bảo hành: 3 năm.
