Wireless Access Controller RUIJIE RG-WS6008

Wireless Access Controller RUIJIE RG-WS6008

Thương hiệu Ruijie
Mã SP Wireless Access Controller RUIJIE RG-WS6008

Chính sách bán hàng

  • Thùng gồm có: Sách hướng dẫn, phụ kiện
  • Bảo hành chính hãng: Sản phẩm bảo hành 1 năm, phụ kiện kèm theo bảo hành 6 tháng (xem điểm bảo hành)
  • Nhận hàng miễn phí 48 tiếng (xem chính sách giao hàng toàn quốc)
  • Đổi sản phẩm lỗi miễn phí trong 1 tháng.
  • Giảm giá 5% đối với các đơn hàng >10 triệu

Wireless Access Controller RUIJIE RG-WS6008

- Thiết bị điều khiển WIFI thế hệ mới.

- Hỗ trợ 6 cổng 1000BASE-T.

- Hỗ trợ 2 cổng 1000BASE-T/1000BASE-X combo.

- Hỗ trợ 1 cổng Console Port.

- Hỗ trợ 1 cổng USB ports.

- Tích hợp sẵn license cho 32 Access Point wifi (Tối đa mở rộng lên đến 224 APs hoặc 448 wall APs).

- Hỗ trợ tối đa: 6.400 users.

- Hỗ trợ  4,094 VLAN.

- LAN Protocols: ARP, VLAN, 802.1p, 802.1q, 802.1d, 802.1w, 802.1s.

- 802.11 LAN Protocols: 802.11, 802.11b, 802.11a, 802.11g, 802.11d, 802.11h, 802.11w, 802.11k, 802.11r, 802.11i, 802.11e, 802.11n, 802.11ac.

- Các chứng nhận: GB9254, EN301 489, GB4943, EN/IEC 60950-1.

- Bảo hành 3 năm

Đặc tính kỹ thuật



Service Ports6x 1000BASE-T ports
2x 1000BASE-T/1000BASE-X ports (combo)
Console Ports1x Console Port
USB Ports2x USB ports
Default Number of Manageable APs32
Maximum Number of Manageable APs224 APs or 448 wall APs (with license upgrade)
Maximum Number of Configurable APs2,048
Maximum Number of Clients6,400
802.11 Performance8Gbps
Maximum Number of Clients Supported by the Built-in Portal1,500
Number of Wireless Users6,400
MAC Address Table16K
Local Authentication300 wireless clients
ARP Table12K
IPv6 Neighbor Table10K
Inter-AC Roaming Switch Time≤50ms
Power Supply-Fixed power supply 100VAC to 240VAC, 50Hz to 60Hz
Power Consumption<40W
802.1Q VLANSupport
ACLStandard IP ACL, Extended IP ACL, MAC-extended ACL, Expert ACL
Bandwidth controlSupport
LAN ProtocolsARP, VLAN, 802.1p, 802.1q, 802.1d, 802.1w, 802.1s
802.11 LAN Protocols802.11, 802.11b, 802.11a, 802.11g, 802.11d, 802.11h, 802.11w, 802.11k, 802.11r, 802.11i, 802.11e, 802.11n, 802.11ac
CAPWAPLayer 2/Layer 3 network topology between an AP and AC
Network Address Translation (NAT) traversal
RoamingIntra-AC roaming, Inter-AC roaming
ForwardingLocal forwarding, Centralized forwarding
Wireless QoS AP-based bandwidth control, WLAN-based bandwidth control, User-based static and smart speed control, Fair balancing
User IsolationAC-based user isolation
AP-based user isolation
WLAN-based user isolation
ReliabilityFast switching between 2 ACs, Multiple ACs redundancy (1:1 A/A and A/S, N:1), Multiple ACs clustering (N:N), Remote Intelligent Perception Technology (RIPT), Service upgrade
STA ManagementAP-based STA access control, SSID-based STA access control, AP-based load balancing, AP traffic-based load balancing, 5G priority access, RSSI threshold
STA RSSI Threshold0 to 100
STA Idle Timeout60 to 86,400 seconds
STA Average Data Rate Threshold8 to 819,200 with the accuracy of 8Kbps
Adjusting Transmit Power of Beacon and Probe ResponseSupport
Offline SyslogSupport
IPv4/v6 SecurityWeb authentication, 802.1x authentication (EAP-PEAP, EAP-SIM, EAP-MD5, EAP-TLS, EAP-TTLS, PEAP-MSCHAPv2, EAP-FAST, EAP-AKA), MAC address authentication
Virtual APSupported
Virtual ACSupported
802.11 Security and EncryptionMultiple SSIDs, SSID hiding, 802.11i-compliant PSK authentication, WPA and WPA2, WEP (WEP/WEP128), WAPI, TKIP, CCMP, Protection against ARP spoofing
Internet Protocols
IPv4 ProtocolsPing, Traceroute, DHCP Server, DHCP Client, DHCP Relay, DHCP Snooping, DNS Client, NTP, Telnet, TFTP Client
IPv6 ProtocolsDNSv6 Client, DHCPv6 Relay, DHCPv6 Server, TFTPv6 Client, FTPv6 Server, FTPv6 Client, IPv6 CAPWAP, ICMPv6, IPv6 Ping, IPv6 Traceroute, Manual tunnel, automatic tunnel
Manual configuration address, automatic local address
IPv4 RoutingStatic routing, OSPF
IPv4 Routing Table Capacity8K
IPv4 Static Routing Table Capacity1K
IPv6 RoutingStatic routing
IPv6 Routing Table Capacity1K
IPv6 Static Routing Table Capacity1K
Management and Maintenance
Network ManagementSNMP v1/v2c/v3, Web management, Syslog
Network Management PlatformWeb management (Smart-web), RG-SNC management, Heat Map diagram
WIS IntegrationSupported
User Access ManagementLogin via console port
Login via Telnet/SSH/FTP
Physical Specification & Others
LED IndicatorsStatus, Link/ACT
Dimensions (W x D x H) (mm)440 × 200 × 43.6
Rack Height1RU
Environmental Specifications
TemperatureOperating Temperature: 0ºC to 45ºC
Storage Temperature: -40ºC to 70ºC
HumidityOperating Humidity: 10% to 90%RH (non-condensing)
Storage Humidity: 5% to 95%RH (non-condensing)
Operating Altitude0-3000m
EMC StandardGB9254
EN301 489
Safety StandardGB4943
EN/IEC 60950-1
